Last updated: 2022-08-12 15:17:20

    This document describes core API class XmagicApi.java of the Tencent Effect SDK used to initialize the SDK, update beauty filter values, and call animated effects.

    Public Member Functions

    API Description
    XmagicApi Constructor.
    updateProperty Updates an attribute and can be called in any thread.
    updateProperties Updates attributes and can be called in any thread.
    setTipsListener Sets the callback function for the animated effect prompt to display the prompt on the frontend page.
    setYTDataListener Sets the callback for data such as face point information (only available in S1-05 and S1-06 packages).
    setAIDataListener Sets the callback of face, gesture, and body detection status.
    onPause Pauses sound playback and can be bound to the onPause lifecycle of Activity.
    onResume Resumes rendering and can be bound to the onResume lifecycle of Activity.
    onDestroy Terminates xMagic, which needs to be called in the GL thread.
    process Method to receive data by SDK rendering, which can be used within the camera data callback function.
    onPauseAudio Call this function when you only need to stop the audio but don't need to release the GL thread.
    sensorChanged Used to determine the current rotation angle of the phone, so as to adjust the basis for AI to recognize the angle of the face.
    isDeviceSupport Passes in the list of animated effect resources into the SDK for check, after which the XmagicProperty.isSupport field identifies whether the atomic capability is available. According to the value of XmagicProperty.isSupport, click restrictions can be controlled at the UI layer or removed from the resource list directly.
    getPropertyRequiredAbilities Passes in a list of animated effect resources and returns a list of the SDK atomic capabilities used by each resource.
    getDeviceAbilities Returns the list of atomic capabilities supported by the current device.
    isSupportBeauty Determines whether the current model supports beauty filters (OpenGL3.0).
    isBeautyAuthorized Determines which beauty filters are supported by the current lic. Only beauty filters of the BEAUTY and BODY_BEAUTY types can be checked. The check result is assigned to the XmagicProperty.isAuth field of each beauty filter object.
    setXmagicStreamType Sets the input data type, which is Android camera data stream by default.
    setXmagicLogLevel Sets the log level of the SDK. We recommend you set it to Log.DEBUG during developing and debugging and to Log.WARN after official release. If it is set to Log.DEBUG after release, many logs will be generated and affect the performance.
    It should be called after new XmagicApi().

    Static Functions

    API Description
    setLibPathAndLoad Sets libPath.

    Public Member Function Description

    XmagicApi

    Constructor.

    XmagicApi(Context context, String resDir)
    XmagicApi(Context context, String resDir,OnXmagicPropertyErrorListener xmagicPropertyErrorListener)


    Parameters

    Parameter Description
    Context context Context.
    String resDir Resource file directory.
    • If the SDK resource files are built into `assets`, before using the SDK for the first time, you need to copy the resources to the app's private directory: set the resource path through XmagicResParser.setResPath(new File(getFilesDir(), "xmagic").getAbsolutePath()) first and then copy the resources through XmagicResParser.copyRes(getApplicationContext()). For more information, see the LaunchActivity.java of the demo.
    • If the SDK resource files are downloaded from the internet, after the download succeeds, set the resource path through XmagicResParser.setResPath(validAssetsDirectory).
    • Get the previously set path through XmagicResParser.getResPath().
    OnXmagicPropertyErrorListener xmagicPropertyErrorListener Error callback API.
    Error codes and descriptions:
    Error Code Description
    -1 An unknown error occurred.
    -100 Failed to initialize 3D SDK resources.
    -200 The GAN material is not supported.
    -300 The device does not support this material component.
    -400 The template JSON content is empty.
    -500 The SDK version is too low.
    -600 Keying is not supported.
    -700 OpenGL is not supported.
    -800 The script is not supported.
    5000 The resolution of the background image to be keyed exceeds 2160 x 3840.
    5001 The memory required by background image keying is insufficient.
    5002 Failed to parse the background video to be keyed.
    5003 The background video to be keyed exceeds 200 seconds.
    5004 The format of the background video to be keyed is not supported.

    updateProperty

    Modifies a beauty filter value, animated effect, or filter and can be called in any thread.

    void updateProperty(XmagicProperty<?> p)


    Parameters

    Parameter Description
    XmagicProperty<?> p Tencent Effect SDK data entity class.
    • Taking "skin smoothening" as an example, you can create an instance as follows:
      new XmagicProperty<>(Category.BEAUTY, null, null, BeautyConstant.BEAUTY_SMOOTH, new XmagicPropertyValues(0, 100, 50, 0, 1)));.
    • Taking "2D animated effect Bunny" as an example, you can create an instance as follows:
      new XmagicProperty<>(Category.MOTION, "video_tutujiang" , "animated effect file path", null, null);.
      For more examples, see the XmagicResParser.java of the demo project.

    updateProperties

    Batch modifies beauty values, animated effects, or filters and can be called in any thread.

    void updateProperties(List<XmagicProperty<?>> properties)


    Parameters

    Parameter Description
    (List<XmagicProperty<?>> properties See the updateProperty method description.

    setTipsListener

    Sets the callback function for the animated effect prompt to display the prompt on the frontend page; for example, some materials will prompt the user to nod, stretch out their palms, or make a finger heart.

    void setTipsListener(XmagicApi.XmagicTipsListener effectTipsListener)


    Parameters

    Parameter Description
    XmagicApi.XmagicTipsListener effectTipsListener Callback function implementation class. The callback is not necessarily in the main thread.

    setYTDataListener

    Sets the callback for data such as face point information.

    void setYTDataListener(XmagicApi.XmagicYTDataListener ytDataListener)
    Sets the callback for data such as face information.
    public interface XmagicYTDataListener {
       void onYTDataUpdate(String data)
    }



    onYTDataUpdate returns a JSON string structure that contains the information of up to 5 faces:

    {
    "face_info":[{
     "trace_id":5,
     "face_256_point":[
       180.0,
       112.2,
       ...
     ],
     "face_256_visible":[
       0.85,
       ...
     ],
     "out_of_screen":true,
     "left_eye_high_vis_ratio:1.0,
     "right_eye_high_vis_ratio":1.0,
     "left_eyebrow_high_vis_ratio":1.0,
     "right_eyebrow_high_vis_ratio":1.0,
     "mouth_high_vis_ratio":1.0
    },
    ...
    ]
    }



    Field description

    Field Type Range Description
    trace_id int [1,INF) Face ID. The same ID points to the same face in the process of continuous stream fetching.
    face_256_point float [0,screenWidth] or [0,screenHeight] 512 values in total for 256 facial keypoints. (0,0) is the top-left corner of the screen.
    face_256_visible float [0,1] Visibility of the 256 facial keypoints.
    out_of_screen bool true/false Whether the face is out of the screen.
    left_eye_high_vis_ratio float [0,1] Percentage of the highly visible points of the left eye.
    right_eye_high_vis_ratio float [0,1] Percentage of the highly visible points of the right eye.
    left_eyebrow_high_vis_ratio float [0,1] Percentage of the highly visible points of the left eyebrow.
    right_eyebrow_high_vis_ratio float [0,1] Percentage of the highly visible points of the right eyebrow.
    mouth_high_vis_ratio float [0,1] Percentage of the highly visible points of the mouth.

    Parameters

    Parameter Description
    XmagicApi.XmagicYTDataListener ytDataListener Callback function implementation class.

    setAIDataListener

    Calls back the point information of the detected face, body parts, and gestures.

    public interface OnAIDataListener {
       void onFaceDataUpdated(List<FaceData> faceDataList);
      void onHandDataUpdated(List<HandData> handDataList);
      void onBodyDataUpdated(List<BodyData> bodyDataList);
    }


    onPause

    Pauses rendering, can be bound to the onPause lifecycle of Activity, and internally calls onPauseAudio only.

    void onPause()


    onResume

    Resumes rendering and can be bound to the onResume lifecycle of Activity.

    void onResume()


    onDestroy

    Clears GL thread resources and needs to be called within the GL thread. Sample code:

    // See the sample code in `MainActivity.java`
    glSurfaceView.queueEvent(() -> {
                  if (mXmagicApi != null) {
                      mXmagicApi.onPause();
                      mXmagicApi.onDestroy();
                  }
              });

    // See the sample code in `ImageInputActivity.java`
    @Override
    protected void onDestroy() {
       if (mHandler != null) {
          mHandler.destroy(() -> {
              if (mXmagicApi != null) {
                  mXmagicApi.onPause();
                  mXmagicApi.onDestroy();
                  }
              });
              mHandler.waitDone();
      }
       XmagicPanelDataManager.getInstance().clearData();
      super.onDestroy();
    }


    process

    Method to receive data by SDK rendering, which can be used within the camera data callback function.

    // Render the texture
    int process(int srcTextureId, int srcTextureWidth, int srcTextureHeight)
    // Render the bitmap
    Bitmap process(Bitmap bitmap, boolean needReset){


    Parameters

    Parameter Description
    int srcTextureId Texture that needs to be rendered.
    id int srcTextureWidth Width of the texture that needs to be rendered.
    int srcTextureHeight Height of the texture that needs to be rendered.
    Bitmap bitmap The recommended maximum size is 2160 x 4096. Larger images have poor face recognition results or cannot get faces recognized and are likely to cause OOM problems. Shrink such images first before passing them in.
    boolean needReset Set needReset to true for the following scenarios.
  • Switch image.
  • Use keying for the first time.
  • Use animated effect for the first time.
  • Use makeup for the first time.

  • onPauseAudio

    Call this function when you only need to stop the audio but don't need to release the GL thread.

    void onPauseAudio()


    sensorChanged

    Used to determine the current rotation angle of the phone, so as to adjust the basis for AI to recognize the angle of the face. This needs to be called in the callback function of the G-sensor.

    void sensorChanged(SensorEvent event, Sensor accelerometer)


    Parameters

    Parameter Description
    SensorEvent event Event entity class returned by the G-sensor callback function onSensorChanged.
    Sensor accelerometer Sample G-sensor.

    isDeviceSupport

    Passes in the list of animated effect resources into the SDK for check, after which the XmagicProperty.isSupport field identifies whether the material is available. According to the value of XmagicProperty.isSupport, click restrictions can be controlled at the UI layer or removed from the resource list directly.

    void isDeviceSupport(List<XmagicProperty<?>> assetsList)


    Parameters

    Parameter Description
    List<XmagicProperty<?>> assetsList List of animated effect materials to be checked.

    getPropertyRequiredAbilities

    Passes in a list of animated effect resources and returns a list of the SDK atomic capabilities used by each resource.
    Use case of this method:
    If you have purchased or made several animated effect materials, calling this method will return the list of atomic capabilities that each material needs to use. For example, material 1 needs to use capabilities A, B, and C, while material 2 needs to use capabilities B, C, and D. Then, you can keep this list on the server. After that, when a user wants to download the materials from the server, the user first gets the list of atomic capabilities supported by the user's phone through the getDeviceAbilities method (for example, the phone has capabilities A, B, and C but not D), and the list is then sent to the server. The server determines that the phone does not have capability D, so it will not deliver material 2 to the user.

    Parameters

    Parameter Description
    List<XmagicProperty<?>> assets List of animated effect resources for which to check the atomic capabilities.

    Response

    Returned value Map<xmagicproperty<?>,ArrayList<string>>:

    • key: animated effect resource material entity class.
    • value: list of used atomic capabilities.

    getDeviceAbilities

    Returns the list of atomic capabilities supported by the current device and needs to be used together with the getPropertyRequiredAbilities method. For more information, see the getPropertyRequiredAbilities description.

    Map<String,Boolean> getDeviceAbilities()


    Response

    Returned value Map<string,boolean>:

    • key: atomic capability name (corresponding to the material capability name).
    • value: whether it is supported by the current device.

    isSupportBeauty

    Determines whether the current model supports beauty filters (OpenGL3.0).

    boolean isSupportBeauty()


    Response

    Returned value boolean: whether beauty filter is supported.


    isBeautyAuthorized

    Determines which face/body beauty filters are supported by the current license. Only beauty filters of the BEAUTY and BODY_BEAUTY types can be checked. The check result is assigned to the XmagicProperty.isAuth field of each beauty filter object. Access to these items can be blocked on the UI if the isAuth field is false.

    void isBeautyAuthorized(List<XmagicProperty<?>> properties)


    Parameters

    Parameter Description
    List<XmagicProperty<?>> properties Beauty filters that need to be checked.

    setXmagicStreamType

    Sets the input data type, which is Android camera data stream (XmagicApi.PROCESS_TYPE_CAMERA_STREAM) by default.

    void setXmagicStreamType(int type)


    Parameters

    Parameter Description
    int type Data source type. Valid values:
    • XmagicApi.PROCESS_TYPE_CAMERA_STREAM: camera data source
    • XmagicApi.PROCESS_TYPE_PICTURE_DATA: image data source

    Static Function Description

    setLibPathAndLoad

    Sets the so file path and triggers loading. If the so file is built into assets, you don't need to call this method. If it is downloaded dynamically, this method needs to be called before authentication and new XmagicApi.

    • If a null value is passed in, the so library will be loaded from the default path. Make sure that it is built into the APK package.
    • If a non-null value is passed in, such as data/data/package name/files/xmagic_libs, the so library will be loaded from this directory.
    static boolean setLibPathAndLoad(String path)



    Parameters

    Parameter Description
    String path Path to store the so library.

    </string,boolean></xmagicproperty<?>
