Background

Tencent Cloud WAF (WAF) supports access to Tencent Cloud CLB (CLB), but it requires a Layer 7 Listener (HTTP/HTTPS):

However, Nginx Ingress uses a Layer 4 CLB Listener by default:

This document shows you how to change the CLB Listener used by Nginx Ingress to a layer-7 listener.

Using the Specify-protocol Annotation

The TKE service supports using the service.cloud.tencent.com/specify-protocol annotation to modify the CLB listener protocol. For details, see Service Extension Protocol.
values.yaml configuration example:
controller:
  service:
    annotations:
      service.cloud.tencent.com/specify-protocol: |
        {
          "80": {
            "protocol": [
              "HTTP"
            ],
            "hosts": {
              "a.example.com": {},
              "b.example.com": {}
            }
          },
          "443": {
            "protocol": [
              "HTTPS"
            ],
            "hosts": {
              "a.example.com": {
                "tls": "cert-secret-a"
              },
              "b.example.com": {
                "tls": "cert-secret-b"
              }
            }
          }
        }
The domain names involved in the actual Ingress rules also need to be configured in the hosts field of the annotation.
An HTTPS listener requires a certificate. First, create a certificate in My Certificates, and then create a Secret in the TKE cluster (in the namespace where Nginx Ingress is located). The Key of the Secret is qcloud_cert_id, and the Value is the corresponding certificate ID. Then refer to the secret name in the annotation.
targetPorts needs to direct the HTTPS port to port 80 (HTTP) of Nginx Ingress to avoid CLB's port 443 traffic being forwarded to Nginx Ingress's port 443 (which would lead to double certificates and forward failure).
If HTTP traffic is not needed, set enableHttp to false.
Note:
To redirect HTTP traffic to HTTPS, find the CLB instance used by Nginx Ingress in the CLB console (the instance ID can be obtained by viewing the YAML file of Nginx Ingress Controller service), and manually configure the redirection rules on the instance page:


Directions

1. Upload the certificate and copy the certificate ID in My Certificates.
2. Create the corresponding certificate secret in the namespace of Nginx Ingress (referencing the certificate ID):
apiVersion: v1
kind: Secret
metadata:
  name: cert-secret-test
  namespace: ingress-nginx
stringData: # Using stringData eliminates the need of manual base64 transcoding
  # highlight-next-line
  qcloud_cert_id: E2pcp0Fy
type: Opaque
3. Configure values.yaml:
controller: # The following configuration replaces the dependent image with the mirror image on docker hub to ensure it can be pulled in the Chinese mainland environment
  image:
    registry: docker.io
    image: k8smirror/ingress-nginx-controller
  admissionWebhooks:
    patch:
      image:
        registry: docker.io
        image: k8smirror/ingress-nginx-kube-webhook-certgen
  defaultBackend:
    image:
      registry: docker.io
      image: k8smirror/defaultbackend-amd64
  opentelemetry:
    image:
      registry: docker.io
      image: k8smirror/ingress-nginx-opentelemetry
  service:
    enableHttp: false
    targetPorts:
      https: http
    annotations:
      service.cloud.tencent.com/specify-protocol: |
        {
          "80": {
            "protocol": [
              "HTTP"
            ],
            "hosts": {
              "test.example.com": {}
            }
          },
          "443": {
            "protocol": [
              "HTTPS"
            ],
            "hosts": {
              "test.example.com": {
                "tls": "cert-secret-test"
              }
            }
          }
        }
4. If needed, you can redirect HTTP to HTTPS automatically by configuring the redirection rule in the CLB console:

5. Deploy test applications and Ingress rules:
apiVersion: v1
kind: Service
metadata:
  labels:
    app: nginx
  name: nginx
spec:
  ports:
    - port: 80
      protocol: TCP
      targetPort: 80
  selector:
    app: nginx
  type: NodePort
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
        - image: nginx:latest
          name: nginx
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: nginx
spec:
  ingressClassName: nginx
  rules:
    - host: test.example.com
      http:
        paths:
          - backend:
              service:
                name: nginx
                port:
                  number: 80
            path: /
            pathType: Prefix
6. After configuring hosts or domain name resolution, test if the feature works properly:



Configuring WAF

After Nginx Ingress is configured, if the corresponding CLB listener has been changed to HTTP/HTTPS, it satisfies the prerequisite for Nginx Ingress to connect to WAF. You can then follow the instructions in the WAF Official Documentation to complete the WAF access to Nginx Ingress.
