syntax = "proto2"; // 指明符合proto2语法规范
package myTcaplusTable; // 自定义包名
import "tcaplusservice.optionv1.proto"; // 这个文件定义了Tcaplus表的一些公共信息,需要在您的表定义中被引用(import)
message player { //使用message定义表,message名即表名
// 必须是指定了主键选项(tcaplusservice.tcaplus_primary_key)的message才能被识别为一张TcaplusDB业务数据表,否则此message只是一个结构体
// 主键选项指定了主键字段名列表,字段名用逗号分割,最多四个字段能够被指定为主键
option(tcaplusservice.tcaplus_primary_key) = "uin,name,region";
// tcaplusservice.tcaplus_index选项指定Tcaplus索引
// 每个索引所包含的索引键必须是主键,并且所有索引字段集合的交集不能为空
option(tcaplusservice.tcaplus_index) = "index_1(uin,region)";
option(tcaplusservice.tcaplus_index) = "index_2(uin,name)";
//option(tcaplusservice.tcaplus_sharding_key) = "uin"; 用户可以自己显式设置索引分片字段。如果用户不显式设置,那系统将默认采用主键字段作为分片字段。
option(tcaplusservice.tcaplus_field_cipher_suite) = "DefaultAesCipherSuite"; // 使用默认的DefaultAesCipherSuite加密函数,非必须设置选项。
option(tcaplusservice.tcaplus_cipher_md5)= "62fee3b53619b7f303c939964c6f2c4b"; //设置加密密码字符串的md5值,非必须设置选项。
// 接下来是表的字段定义
// TcaplusDB 表支持以下的数据类型:
// 非嵌套类型:int32, int64, uint32, uint64, sint32, sint64, bool, fixed64, sfixed64, double, fixed32, sfixed32, float, string, bytes
// 嵌套类型:message
// Tcaplus支持REQUIRED, OPTIONAL和REPEATED作为字段修饰符
// 主键字段 (最多4个)
required int64 uin = 1; // 主键字段必须被required类型修饰,并且不能是嵌套类型
required string name = 2[(tcaplusservice.tcaplus_crypto) = true]; //message中string和bytes类型的字段可以指定为加密字段,非必须设置选项
required int32 region = 3;
// 一张表最多只能包含4个主键字段
// 普通值字段
required int32 gamesvrid = 4; // 普通字段可以被required,optional或repeated类型修饰
optional int32 logintime = 5 [default = 1];
repeated int64 lockid = 6 [packed = true]; // repeated修饰的字段需要指定packed=true选项
optional bool is_available = 7 [default = false]; //optional类型字段可以指定默认值
optional pay_info pay = 8; // 值字段的类型可以是自定义的结构体类型
}
message pay_info { //使用message定义结构体
required int64 pay_id = 1;
optional uint64 total_money = 2;
optional uint64 pay_times = 3;
optional pay_auth_info auth = 4;
message pay_auth_info { // 结构体类型支持嵌套定义
required string pay_keys = 1;
optional int64 update_time = 2;
}
}
