Using COS for Backup and Restoration

Last updated: 2022-05-05 16:58:45

    Creating a Repository

    You can create a repository by running the following command:

    PUT _snapshot/my_cos_backup
       "type": "cos",
       "settings": {
           "app_id": "xxxxxxx",
           "access_key_id": "xxxxxx",
           "access_key_secret": "xxxxxxx",
           "bucket": "xxxxxx",
           "region": "ap-guangzhou",
           "compress": true,
           "chunk_size": "500mb",
           "base_path": "/"
    • app_id: APPID of your Tencent Cloud account.
    • access_key_id: SecretId of your Tencent Cloud API key.
    • access_key_secret: SecretKey of your Tencent Cloud API ley.
    • bucket: COS bucket name, which cannot contain the -{appId} prefix.
    • region: COS bucket region, which must be the same region as that of the ES cluster. For more information about regions, see Regions and Availability Zones.
    • compress:true by default, which means the stored index metadata will be compressed.
    • base_path: Backup directory.

    Listing Repository Information

    You can get repository information via GET _snapshot or get the information of a specified repository via GET _snapshot/my_cos_backup.

    Creating a Snapshot Backup

    Backing up all indices

    Back up all indices in the ES cluster to the repository my_cos_backup and name it snapshot_1.

    PUT _snapshot/my_cos_backup/snapshot_1

    This command will return a response immediately and be executed asynchronously in the background until the end. If you want to wait for the execution to complete before returning, you can add the wait_for_completion parameter. The duration of the command execution depends on the index size.

    PUT _snapshot/my_cos_backup/snapshot_1?wait_for_completion=true

    Backing up specified indices

    You can specify the indices to be backed up when creating a snapshot. If the value of the indices parameter is multiple indices, they should be separated by , with no spaces.

    PUT _snapshot/my_cos_backup/snapshot_2
       "indices": "index_1,index_2"

    Querying a Snapshot

    Query the information of a single snapshot:

    GET _snapshot/my_cos_backup/snapshot_1

    This command returns the information about the snapshot:


    When the value of the state field is SUCCESS, the snapshot backup is completed.

       "snapshots": [
               "snapshot": "snapshot_1",
               "uuid": "zUSugNiGR-OzH0CCcgcLmQ",
               "version_id": 5060499,
               "version": "5.6.4",
               "indices": [
               "state": "SUCCESS",
               "start_time": "2018-05-04T11:44:15.975Z",
               "start_time_in_millis": 1525434255975,
               "end_time": "2018-05-04T11:45:29.395Z",
               "end_time_in_millis": 1525434329395,
               "duration_in_millis": 73420,
               "failures": [],
               "shards": {
                   "total": 3,
                   "failed": 0,
                   "successful": 3

    Deleting a Snapshot

    Delete a specified snapshot:

    DELETE _snapshot/my_cos_backup/snapshot_1

    If the creation of the snapshot hasn't been competed, the snapshot deletion command will still be executed and cancel the creation of the snapshot.

    Restoring Indices from a Snapshot

    1. Restore all indices backed up in a snapshot to the ES cluster:
      POST _snapshot/my_cos_backup/snapshot_1/_restore
    • If snapshot_1 contains five indices, all of them will be restored to the ES cluster.
    • You can also rename the indices through an additional option which allows you to match the index name by pattern and provide a new name through the restoration process. Use this option if you want to restore old data to verify the content or perform other operations without replacing existing data.
    1. Restore a single index from a snapshot and provide an alternate name:
      POST /_snapshot/my_cos_backup/snapshot_1/_restore
      "indices": "index_1",
      "rename_pattern": "index_(.+)",
      "rename_replacement": "restored_index_$1"
    • indices: Only restores index_1 and ignores other indices in the snapshot.
    • rename_pattern: Finds the index being restored that can be matched by the specified pattern.
    • rename_replacement: Renames the matching index to the name specified in this parameter.

    Querying the Status of Snapshot Restoration

    You can check the status of snapshot restoration and monitor the progress by running the _recovery command.

    1. You can call the following API separately in the specified index to be restored:

      GET index_1/_recovery
    2. This command will return the restoration status of each shard of the specified index:

      "sonested": {
          "shards": [
                  "id": 1,
                  "type": "SNAPSHOT",
                  "stage": "INDEX",
                  "primary": true,
                  "start_time_in_millis": 1525766148333,
                  "total_time_in_millis": 8718,
                  "source": {
                      "repository": "my_cos_backup",
                      "snapshot": "snapshot",
                      "version": "5.6.4",
                      "index": "index_1"
                  "target": {
                      "id": "TlzmxJHwSqyv4rhyQfRkow",
                      "host": "",
                      "transport_address": "",
                      "ip": "",
                      "name": "node-1"
                  "index": {
                      "size": {
                          "total_in_bytes": 1374967573,
                          "reused_in_bytes": 0,
                          "recovered_in_bytes": 160467084,
                          "percent": "11.7%"
                      "files": {
                          "total": 132,
                          "reused": 0,
                          "recovered": 20,
                          "percent": "15.2%"
                      "total_time_in_millis": 8716,
                      "source_throttle_time_in_millis": 0,
                      "target_throttle_time_in_millis": 0
                  "translog": {
                      "recovered": 0,
                      "total": 0,
                      "percent": "100.0%",
                      "total_on_start": 0,
                      "total_time_in_millis": 0
                  "verify_index": {
                      "check_index_time_in_millis": 0,
                      "total_time_in_millis": 0
    • type: Describes the nature of the restoration, which means this shard is restored from a snapshot.
    • source: Describes the specific snapshot and repository as the source of restoration.
    • percent: Describes the restoration status. 94% of the files in the particular shard has now been restored, so it will be completely restored soon.

    The output lists all the indices that are being restored and all the shards in them. Each shard contains statistics such as the start/stop time, duration, percentage of restoration, and number of bytes transferred.

    Canceling Snapshot Restoration

    DELETE /restored_index_1

    If restored\_index\_1 is being restored, this deletion command will stop the restoration and delete all data that has been restored to the cluster.
