Scenarios

This document describes how to use open-source SDK to send and receive messages by using the SDK for Java as an example and helps you better understand the message sending and receiving processes.

Prerequisites

• You have created the required resources.
• You have installed JDK 1.8 or later
• You have installed Maven 2.5 or later
• You have downloaded the demo

Directions

1. Introduce dependencies in a Java project and add the following dependencies to the pom.xml file. This document uses a Maven project as an example.
   <dependency>
        <groupid>org.apache.pulsar</groupid>
        <artifactid>pulsar-client</artifactid>
        <version>2.7.2</version>
   </dependency>

Note：

• SDK 2.7.2 or later is recommended.
• SDK 2.7.4 or later is recommended if you use the batch message sending and receiving feature (BatchReceive) of the client.

2. Create a Pulsar client.

   PulsarClient pulsarClient = PulsarClient.builder()
                  // Service access address
                  .serviceUrl(SERVICE_URL)
                  // Role token
                  .authentication(AuthenticationFactory.token(AUTHENTICATION)).build();

   Parameter	Description
   SERVICE_URL	Cluster access address, which can be viewed and copied on the Cluster page in the console.
   AUTHENTICATION	Role token, which can be copied in the **Token** column on the Role Management page.

3. Create a producer.

   // Create a producer of the `byte[]` type
   Producer<byte[]> producer = pulsarClient.newProducer()
       // Complete path of the topic in the format of `persistent://cluster (tenant) ID/namespace/topic name`
       .topic("persistent://pulsar-xxx/sdk_java/topic1").create();

Note：

You need to enter the complete path of the topic name, i.e., persistent://clusterid/namespace/Topic, where the clusterid/namespace/topic part can be copied directly from the Topic page in the console.

4. Send the message.

   // Send the message
   MessageId msgId = producer.newMessage()
       // Message content
       .value("this is a new message.".getBytes(StandardCharsets.UTF_8))
       // Business key
       .key("youKey")
       // Business parameter
       .property("mykey", "myvalue").send();

5. Release the resources.

   // Disable the producer
   producer.close();
   // Disable the client
   pulsarClient.close();

6. Create a consumer.

   // Create a consumer of the `byte[]` type (default type)
   Consumer<byte[]> consumer = pulsarClient.newConsumer()
       // Complete path of the topic in the format of `persistent://cluster (tenant) ID/namespace/topic name`, which can be copied from the **Topic** page.
       .topic("persistent://pulsar-xxx/sdk_java/topic1")
       // You need to create a subscription on the topic details page in the console and enter the subscription name here
       .subscriptionName("sub_topic1")
       // Declare the exclusive mode as the consumption mode
       .subscriptionType(SubscriptionType.Exclusive)
       // Configure consumption starting at the earliest offset; otherwise, historical messages may not be consumed
       .subscriptionInitialPosition(SubscriptionInitialPosition.Earliest)
       // Subscription
       .subscribe();

Note：

• You need to enter the complete path of the topic name, i.e., persistent://clusterid/namespace/Topic, where the clusterid/namespace/topic part can be copied directly from the Topic page in the console.

• You need to enter the subscription name in the subscriptionName parameter, which can be viewed on the Consumption Management page.

7. Consume the message.

   // Receive a message corresponding to the current offset
   Message<byte[]> msg = consumer.receive();
   MessageId msgId = msg.getMessageId();
   String value = new String(msg.getValue());
   System.out.println("receive msg " + msgId + ",value:" + value);
   // Messages must be acknowledged after being received; otherwise, the offset will be held in the position of the current message, causing message heap.
   consumer.acknowledge(msg);

8. Use the listener for consumption.

   // Message listener
   MessageListener<byte[]> myMessageListener = (consumer, msg) -> {
       try {
           System.out.println("Message received: " + new String(msg.getData()));
           // Return `ack` as the acknowledgement
           consumer.acknowledge(msg);
       } catch (Exception e){
           // Return `nack` if the consumption fails
           consumer.negativeAcknowledge(msg);
       }
   };
   pulsarClient.newConsumer()
       // Complete path of the topic in the format of `persistent://cluster (tenant) ID/namespace/topic name`, which can be copied from the **Topic** page.
       .topic("persistent://pulsar-mmqwr5xx9n7g/sdk_java/topic1")
       // You need to create a subscription on the topic details page in the console and enter the subscription name here
       .subscriptionName("sub_topic1")
       // Declare the exclusive mode as the consumption mode
       .subscriptionType(SubscriptionType.Exclusive)
       // Set the listener
       .messageListener(myMessageListener)
       // Configure consumption starting at the earliest offset; otherwise, historical messages may not be consumed
       .subscriptionInitialPosition(SubscriptionInitialPosition.Earliest)
       .subscribe();

9. Log in to the TDMQ for Pulsar console, click Topic > Topic Name to enter the Consumption Management page, and click the triangle below a subscription name to view the production and consumption records.


Note：

The above is a brief introduction to the way of publishing and subscribing to messages. For more operations, see Demo or Pulsar Java client.
